Video Playback Engine | H.265 4K@60p / H.264 4K@30p / HTML5 |
Display Resolution | 4K UHD / 3840*2160 @60fps |
HDMI Output | 1 x HDMI 2.0 / support HDCP |
HDMI CEC | Yes |
System |
Operating System | Android 5.1 / Android 7.1 / Android 8 / Android 10 / Android 12 |
Programming API | HTML5, W3C SMIL |
CPU | ARM Quad-core / 1.8GHz |
GPU | Mali-T764 |
Memory | 2GB |
Storage | 32GB eMMC |
I/O Interface | |
Ethernet | 10/100/1000 Gigabit BASE-T |
WLAN | 802.11 b/g/n |
Bluetooth | Yes |
USB | 2 x USB2.0 |
ADB | 1 x Micro USB for ADB |
Analog Audio | 1 x 3.5mm stereo headphone output / Mic-in (combo jack) |
Digital Audio | 1 x SPDIF output |
COM port | 1 x RS-232 control port |
Storage Expansion | 1 x Micro SDHC slot |
Reset Button | Yes |
Power Status LED | Yes |
Mechanical & Environment |
Dimension (WxDxH) | 165x118.5x27 mm(6.49" x 4.66" x 1.06" inch) |
Mounting | Easy wall mount / VESA mount 10x10 cm |
Operating temperature | -40°C to 70°C (-40°F to 158°F) |
Storage temperature | -40°C to 80°C (-40°F to 176°F) |
Housing | durable Aluminum |
Anti-theft lock compatible | Yes |
Cable Retention Kit | included |
Regulatory | CE/FCC/RoHS/BSMI/VCCI/CB |
Power Adapter | DC12V, 1.5A |
